| NPR-HD Specifications | |
| GVWR/GCWR | 14,500/20,500 lbs. |
| Body/Payload Allowance | 8,070-8,336 lbs. |
| GAWR | |
| -Front | 5,360 lbs. |
| -Rear | 9,880 lbs. |
| Front Axle Capacity | 6,830 lbs. |
| Rear Axle Capacity | 14,550 lbs. |
| -Ratio | 4.555 (A/T), 4.300 (M/T) |
| Suspension, Front & Rear | |
| -F/R Springs | Tapered/Multi-Leaf |
| -Capacity | 6,830/9,880 lbs. |
| Frame | |
| -Section Modulus | 7.20 in.3 |
| -Resistance Bending Moment | 316,800 lbs.-ft./in. |
| Service Brakes | Vacuum/Hydraulic with 4-Channel ABS |
| -Front/Rear | Disc/Drum |
| Exhaust Brake | Standard |
| Transmission | |
| -Standard | Aisin A465 6-speed auto with double overdrive and lock-up 2nd-6th gears |
| -Optional | Isuzu MZZ 6-speed manual |
| Engine | Isuzu 4HK1-TC turbocharged intercooled diesel |
| -Displacement | 5.2 L (317 in.3) |
| -Engine Power | 210 HP @ 2,550 rpm (A/T), 190 HP @ 2,650 rpm (M/T) |
| -Engine Torque | 441 lbs./ft. @ 1,850-2,550 rpm (A/T), 387 lbs./ft. @ 1,600-2,650 rpm (M/T) |
| -Oil Level Indicator | Dash-mounted oil level check switch and light |
| Limited Slip Differential | Optional |
| Alternator | 110-amp |
| Batteries | 2 Maintenance-Free, 750-CCA |
| Tires | 215/85R-16E (10-ply) |
| Steering | Integral Hydraulic Power |
| Steering Column | Tilt & Telescopic |
| Fuel Tank | |
| -Standard | 30 Gal. in-rail |
| -Optional | 33 Gal. right rail |
| Fuel/Water Separator | Dual fuel filter with dash-mounted indicator light. |
| Dimensions | |
| -Wheelbase (in.) | 109.0, 132.5, 150.0, 176.0 |
| -Cab to Axle (in.) | 86.5, 110.0, 127.5, 153.5 |
| -Cab to End of Frame (in.) | 129.6, 153.1, 170.6, 196.6 |
| -Back of Cab (in.) | 7.7, 7.7, 10.2, 10.2 |
| -Overall Length (in.) | 200.5, 224.0, 241.5, 267.5 |
| -Body Length (ft.) | 10-12, 14, 16-18, 20 |
| -Overall Width (in.) | 81.3 |
| -Axle Width (in.) | 65.6 |
| -Overall Height (in.) | 90.8 |
